The first vanity was a traditional wooden cabinet with two white rectangular sinks and gold faucets. The surrounding bathroom already had glossy black subway tile, blue mosaic wall tile, and two gold-framed mirrors. With the sinks in place, we laid the templates over the vanity and traced the areas that needed to be cut out, recording the clearances along the front and sides of each fixture.
Drop-in sinks need particular attention because the sink rim sits above the countertop while the basin extends through the opening. The cutout has to follow the sink manufacturer's requirements, and the remaining stone needs to provide the intended support around the fixture. We marked the sink positions directly on the templates, including the adjustments needed around the sink edges. One template also carried the instruction “WALL NO B/S,” meaning no stone backsplash was planned along that wall.
The second bathroom had a very different cabinet layout, with dark blue and glossy gray finishes, long horizontal handles, and separate openings for the sinks. The cabinets were installed, but the plumbing connections and wall behind them were still exposed. We templated directly over the cabinet frames, marking the sink openings and the finished countertop perimeter before fabrication.
The drawings showed two double-sink layouts with slightly different dimensions. One measured approximately 72 1/4 by 22 5/8 inches, while the other measured about 72 1/2 by 20 3/4 inches. We also recorded a 24 1/2-inch measurement and an 18 7/8-inch measurement at one of the sink openings. I wouldn't use the same template for both vanities simply because they have two sinks and almost the same width. The depth, sink placement, and cabinet construction are different, and even a small discrepancy becomes noticeable when the sinks are already there.
The vanity depth is something I pay attention to on every bathroom project. A common cabinet depth is around 21 inches, with a countertop depth of approximately 22 1/2 inches, but that's only a standard starting point. Here, the actual measurements gave us two different countertop depths. We followed the cabinets and the intended sink positions rather than adjusting the project to fit a standard number.
